Description
|
Model |
MW-LCW1000/1500/2000w |
|
Laser power |
1000W/1500w/2000w |
|
Working mode |
Dual AxisMulti-Mold |
|
Laser source |
Brand JPT |
|
Laser wavelength |
1080±5nm |
|
Repetition frequency range |
1-5000HZ |
|
Power Adjustment |
10%~100% |
|
Output beam diameter (mm) |
5~8（1/e2） |
|
Fiber length |
10M |
|
Voltage |
Single Phase 220V, 50HZ |
|
Scan width |
0.1-30CM |
|
Cooling system |
industrial double temperature and double control water chiller |
|
Fiber length |
10M |
|
Temperature range of working environment |
5-40 ℃ |
|
Humidity range of working environment |
30%～80% |
|
Cleaning thickness range |
0.01mm~4mm |
|
Applicable materials |
Carbon sheet, stainless steel, galvanized sheet etc |
|
Scan speed |
0-7000mm/s |
|
Size |
830mm×1130mm×1300mm |
|
Weight |
220KGs |
